FocusTvButton

September 14, 2023

Light wrapper of UIButton that allows extra customization for tvOS

If you would like to have the same level of customization in tableview cells, you should definitely check out TvOSCustomizableTableViewCell

Description

FocusTvButton allows the customization of UIButtons in tvOS, adding extra properties to customize layout attributes which are not customizable on UIButtons out of the box.

Custom properties:

Focused background color
Unfocused background color
Selected background color
Corner radius
Scale factor when focused
Shadow radius when focused
Shadow opacity when focused
Shadow color
Shadow offset when focused
Duration of the focus animation
Title color when focuses/unfocused

Two color, linear gradient properties:

Focused background end color
Unfocused background end color
Selected background end color
gradient start & end points

A simple two color, linear gradient can be configured by setting either “background end” color properties. If neither “background end” color properties are set then FocusTvButton will use a solid background color by default.

Requirements

tvOS 10.2+
Xcode 11.0+

Usage

FocusTvButton can be integrated both programmatically or embedded in a xib file.

Programmatically

FocusTvButton is a subclass of UIButton, so it can be created and used as a regular UIButton.



                                                let myButton = FocusTvButton()

myButton.focusedBackgroundColor = .red

myButton.normalBackgroundColor = .white

myButton.cornerRadius = 12.0
// with optional gradient

myButton.focusedBackgroundEndColor = .green

myButton.normalBackgroundColor = .black

myButton.gradientStartPoint = .zero

myButton.gradientEndPoint = CGPoint(x: 0, y: 1)

Embedded in a xib or storyboard file

Due to the fact that FocusTvButton is a subclass of UIButton, the first step is to drag and drop a regular UIButton from the Object library to your view.

Then change the value of “Custom Class” to “FocusTvButton”, and the Button type to “Custom” to avoid the default focus behavior.

And that’s all…

The custom properties can be configured directly on the Storyboard using IBInspectables.

Installation

Cocoapods

CocoaPods is a dependency manager for Cocoa projects. You can install it with the following command:



                                                $ gem install cocoapods

To integrate FocusTvButton into your Xcode project using CocoaPods, specify it in your Podfile:



                                                source ‘https://github.com/CocoaPods/Specs.git’

platform :tvos, ‘9.0’

use_frameworks!
target ‘<Your Target Name>’ do

pod ‘FocusTvButton’, ‘~> 3.1.1’

end

Then, run the following command:



                                                $ pod install

Carthage

Carthage is a decentralized dependency manager that builds your dependencies and provides you with binary frameworks.

You can install Carthage with Homebrew using the following command:



                                                $ brew update

$ brew install carthage

To integrate FocusTvButton into your Xcode project using Carthage, specify it in your Cartfile:



                                                github “dcordero/FocusTvButton” ~> 3.1.1

Run carthage update to build the framework and drag the built FocusTvButton.framework into your Xcode project.

Manually

If you prefer, you can also integrate FocusTvButton into your project manually, just copying FocusTvButton.swift to your project.
