SwiftyFORM

November 23, 2023

SwiftyFORM is a lightweight iOS framework for creating forms

Because form code is hard to write, hard to read, hard to reason about. Has a slow turn around time. Is painful to maintain.

SwiftyFORM demo on YouTube

Requirements

iOS 12+
Xcode 12+
Swift 5.1+

Features

Several form items, such as textfield, buttons, sliders
Some form items can expand/collapse, such as datepicker, pickerview
You can create your own custom form items
Align textfields across multiple rows
Form validation rule engine
Shows with red text where there are problems with validation Strongly Typed
Pure Swift
No 3rd party dependencies

USAGE

Tutorial 0 – Static text



                                                import SwiftyFORM

class MyViewController: FormViewController {

override func populate(_ builder: FormBuilder) {

builder += StaticTextFormItem().title(“Hello”).value(“World”)

}

}

Tutorial 1 – TextField



                                                import SwiftyFORM

class MyViewController: FormViewController {

override func populate(_ builder: FormBuilder) {

builder += TextFieldFormItem().title(“Email”).placeholder(“Please specify”).keyboardType(.emailAddress)

}

}

Tutorial 2 – Open child view controller



                                                import SwiftyFORM

class MyViewController: FormViewController {

override func populate(_ builder: FormBuilder) {

builder += ViewControllerFormItem().title(“Go to view controller”).viewController(FirstViewController.self)

}

}

Advanced – date picker



                                                class DatePickerBindingViewController: FormViewController {

override func populate(_ builder: FormBuilder) {

builder += datePicker

builder += incrementButton

builder += decrementButton

builder += SectionFormItem()

builder += summary

updateSummary()

}
lazy var datePicker: DatePickerFormItem = {

let instance = DatePickerFormItem()

instance.title = “Date”

instance.datePickerMode = .date

instance.behavior = .expandedAlways

instance.valueDidChangeBlock = { [weak self] _ in

self?.updateSummary()

}

return instance

}()
lazy var incrementButton: ButtonFormItem = {

let instance = ButtonFormItem()

instance.title = “Next Day”

instance.action = { [weak self] in

self?.increment()

}

return instance

}()
lazy var decrementButton: ButtonFormItem = {

let instance = ButtonFormItem()

instance.title = “Previous Day”

instance.action = { [weak self] in

self?.decrement()

}

return instance

}()
lazy var summary: StaticTextFormItem = {

return StaticTextFormItem().title(“Date”).value(“-“)

}()
func updateSummary() {

summary.value = “\(datePicker.value)”

}
func offsetDate(_ date: Date, days: Int) -> Date {

var dateComponents = DateComponents()

dateComponents.day = days

let calendar = Calendar.current

guard let resultDate = calendar.date(byAdding: dateComponents, to: date) else {

return date

}

return resultDate

}
func increment() {

datePicker.setValue(offsetDate(datePicker.value, days: 1), animated: true)

updateSummary()

}
func decrement() {

datePicker.setValue(offsetDate(datePicker.value, days: -1), animated: true)

updateSummary()

}

}

Advanced – Validation



                                                class ChangePasswordViewController: FormViewController {

override func populate(_ builder: FormBuilder) {

builder.navigationTitle = “Password”

builder += SectionHeaderTitleFormItem().title(“Your Old Password”)

builder += passwordOld

builder += SectionHeaderTitleFormItem().title(“Your New Password”)

builder += passwordNew

builder += passwordNewRepeated

builder.alignLeft([passwordOld, passwordNew, passwordNewRepeated])

}
lazy var passwordOld: TextFieldFormItem = {

let instance = TextFieldFormItem()

instance.title(“Old password”).password().placeholder(“required”)

instance.keyboardType = .numberPad

instance.autocorrectionType = .no

instance.validate(CharacterSetSpecification.decimalDigitCharacterSet(), message: “Must be digits”)

instance.submitValidate(CountSpecification.min(4), message: “Length must be minimum 4 digits”)

instance.validate(CountSpecification.max(6), message: “Length must be maximum 6 digits”)

return instance

}()
lazy var passwordNew: TextFieldFormItem = {

let instance = TextFieldFormItem()

instance.title(“New password”).password().placeholder(“required”)

instance.keyboardType = .numberPad

instance.autocorrectionType = .no

instance.validate(CharacterSetSpecification.decimalDigitCharacterSet(), message: “Must be digits”)

instance.submitValidate(CountSpecification.min(4), message: “Length must be minimum 4 digits”)

instance.validate(CountSpecification.max(6), message: “Length must be maximum 6 digits”)

return instance

}()
lazy var passwordNewRepeated: TextFieldFormItem = {

let instance = TextFieldFormItem()

instance.title(“Repeat password”).password().placeholder(“required”)

instance.keyboardType = .numberPad

instance.autocorrectionType = .no

instance.validate(CharacterSetSpecification.decimalDigitCharacterSet(), message: “Must be digits”)

instance.submitValidate(CountSpecification.min(4), message: “Length must be minimum 4 digits”)

instance.validate(CountSpecification.max(6), message: “Length must be maximum 6 digits”)

return instance

}()

}

INSTALLATION

Swift Package Manager

With Swift Package Manager support in the latest Xcode, installation has never been easier.

Open your Xcode project -> File -> Swift Packages -> Add Package Dependency...

Search for SwiftyFORM and specify the version you want. The latest tagged release is usually a good idea.

CocoaPods

To integrate SwiftyFORM into your Xcode project using CocoaPods, specify the following in your Podfile:



                                                source ‘https://github.com/CocoaPods/Specs.git’

swift_version = ‘5.0’

platform :ios, ‘12.0’

use_frameworks!
target ‘MyApp’ do

pod ‘SwiftyFORM’, ‘~> 1.8’

end

Then, run the following command:



                                                $ pod install

Carthage

Link to demo project that shows a minimal SwiftyFORM app using Carthage.

To integrate SwiftyFORM into your Xcode project using Carthage, specify it in your Cartfile:



                                                github “neoneye/SwiftyFORM” ~> 1.8

Then, run the following command:



                                                $ carthage update

Finally, add SwiftyFORM.framework (will be built by Carthage under Carthage/Build/iOS/) to your project’s Linked Frameworks and Libraries in the General tab, and add a new Run Script Build Phase:

Set /bin/bash as the shell
write /usr/local/bin/carthage copy-frameworks in the script body
add $(SRCROOT)/Carthage/Build/iOS/SwiftyFORM.framework to the input files

Manual

Open up Terminal application and cd into your iOS project directory
ONLY IF your project is not already initialized as a git repository, run



                                                $ git init

Add SwiftyFORM as a submodule by running



                                                $ git submodule add https://github.com/neoneye/SwiftyFORM.git

In the Project Navigator, select your application project and go to “Targets” -> “General”
Open the project folder and drag the SwiftyFORM.xcodeproj file into the “Frameworks, Libraries, and Embedded Content” tab of your application.
Click the + button under the “Frameworks, Libraries, and Embedded Content” section and Add the SwiftyFORM.framework
